Gerber Scientific Products  GERBER Solara |
 |
| | |
|
|
| |
| Information |
|
|
|
|
The GERBER SOLARA UV2 is a large format, hybrid, ultraviolet (UV) inkjet printer. So versatile and intelligent, SOLARA UV2 prints either roll-to-roll or as a flatbed and can accommodate a variety of materials up to 60" wide including rigid materials up to 1/2" thick (13 mm). With only a small conversion process of the included flatbed
table, the SOLARA UV2 can be easily switched to accept different material types, enabling shops to run a full
material portfolio |
| Printing Technology |
Piezo, drop-on-demand |
| Print Head Set |
One print head per color |
| Color |
6 colors: C, M, Y, K, V, G |
| Resolution |
300 x 360 dpi native resolution,
600 dpi apparent resolution |
| Max Printing Width |
60" (Full-Bleed rigid material) |
| Flexible Materials Width |
Up to 60" |
| Dimension |
8.75' (w) x 4.75' (h) x 3.33' (d) |
| Drying Method |
2 UV lamps |
| Production Capacity |
75 ft2/hr 2-pass |
| Inkset |
Gerber UV Inks - 230 ml cassettes |
| RIP Operating System |
Gerber ImageRIP™ Pro by Onyx® |
| Standard Data Interface |
Ethernet TCP/IP |
| Power Range |
220 VAC +/- 10%, 50/60 Hz, 20 A |
| Operating Temperature |
65-80° F |
| Operating Humidity |
40-60% RH (Not condensing) |
| Installation Altitude |
8,000', 2,438 m or less |
| Venting |
No special ventilation required |
|
|
|
|
